R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit

R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit

Products - Refrigerant Recovery Machine
  • Condition
    New
  • Applicable Industries
    Machinery Repair Shops, Manufacturing Plant, Retail, Food & Beverage Shops, Air Conditioner Repair
  • Weight (KG)
    270
  • Showroom Location
    None
  • Video Outgoing-inspection
    Provided
  • Machinery Test Report
    Provided
  • Warranty Of Core Components
    1 Year
  • Core Components
    Motor, Compressor
  • Type
    Oil-less
  • Warranty
    1 Year
  • Approved Refrigerants
    R11,R123,R245FA,R1233ZD Ect
  • Compressor Type
    4HP Oil-free
  • Power Supply
    380V/50Hz, 3PH
  • Operating Temperature
    0°C To 50°C
  • Vapor Recovery Rate
    96Kg/H To 180Kg/H
  • Pull/push Recovery Rate
    2400Kg/H To 4000Kg/H
  • Suction Pressure
    -0.09Mpa ~ +0.15MPa
  • Input/Output
    3/4'' SAE
  • After-sales Service Provided
    Video Technical Support
  • Port
    Shanghai
  • Place of Origin
    Jiangsu, China
  • Brand Name
    CM
  • Certification
    ISO &CE
  • Model Number
    CMR123-20
  • Minimum Order Quantity
    1 Unit
  • Price
    $6,660.00/cartons >=1 cartons
  • Packaging Details
    Fully closed wood case
  • Supply Ability
    200 Unit/Units per Month

R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit

  • R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit
  • R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit
  • R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit
  • R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit
  • R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit
  • R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit
Get Price Contact Now
Product Description
CMR123 Low Pressure Refrigerant Recovery/Recharge Machine Series is specially designed for low pressure refrigerants R123, R141B,R245FA, R1233zd etc, combined with recovery and vacuumfunctions. It’s helpful for maintenance of low pressure chillers and refrigeration equipment.

Details Images
R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit 0
R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit 1
R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit 2
Our Advantages
R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit 3
FEATURES

1- Adopt 4-cylinder oil-free piston compressors special for the low pressure refrigerant recovery;
2- Water-cooled type design make sure the normal running during hot environment;
3- Reversing valve design is convenient for recovery method switching, no need to change the connection horse;
4- High speed recovery rate, the compressor displacement is up to 20m3/hr or 40m3/hr;
5- The functions of recovery and vaccum are combined together, it's so easy for operation;
6- Optimized system design and full safety protection, long time working performance is excellent;
7- Air separator function is custom-designed (Optional).

Product Paramenters
Model
CMR123-20
CMR123-40
Compressor Type
Oil free piston compressor

Compressor Power
2 HP
4 HP
Power Supply
380V/50HZ/3PH
 4L/S
Vapor Recovery Speed
≤ 96Kg/hr
≤ 180Kg/hr
Push/Pull Liquid Recovery Speed
≤ 2400Kg/hr
≤ 4000Kg/hr
Operating Temperature
-5°C to 45°C
360*360*120mm
Suction Pressure
-0.09Mpa ~ +0.15MPa
0~40kg (Standard); 0~100/150kg (Optional)
Discharge Pressure
0 ~ 3bar

Input/Output Pipe Size
3/4'' SAE
3/4'' SAE
Applicable Refrigerant
Low pressure refrigerants like: R123, R1233ZD, R11, R245FA, R141B
2.5 kg/min
Dimension Size(L*W*H)
830*750*750mm
830*750*750mm
Net Weight
120kg
170kg



Recycling Operation
Cooperation Partners & Cases
R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit 4
We had cooperated with global well-known refrigeration equipment manufacturer for many years, especially for the cooperation with YORK Air Conditioning, the deep cooperation of the parties had lasted for 12 years.
No.
Partner Name
Main Product Type
Cooperation Time
1
YORK Air Conditioning
Refrigerant recovery machine
11 years
2
CARRIER Air Conditioning
Refrigerant recovery/recharge machine
06 years
3
MCQUAY Air Conditioning
Refrigerant recovery/recharge machine
09 years
4
CLIMAVENETA Air Conditioning
Refrigerant recovery/recharge machine
04 years
5
TICA Air Conditioning
Refrigerant recovery/recharge machine
08 years



CERTIFICATES
R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit 5




R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit 6







PROJECT CASES
R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit 7



SPECIAL UNITS:
R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit 8
Packing&Shipping
Bulk packing: Large pallet + Straps + Wrapping film
R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit 9
R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit 10
R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit 11
R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit 12
Company Introduction
CM Refrigerant recovery machine (recovery/recharge/reclaim/vacuum /etc)are widely used in the field of HVAC/R. CM is a
comprehensive hi-tech. Enterprise specialized in R&D, manufacture, sales of products for HVAC/R industry.

CM factory, Nanjing Wonfulay Precision Machinery Company Ltd, is located in Nanjing, China. Ever since its establishment in 1990s, CM dedicates itself to R&D and manufacturer of refrigerant recovery systems including recovery / recharge / reclaim / vacuum, etc. With its unremitting efforts and more than 20 years of experience, their refrigerant recovery systems have got several national and international patents and their machines have earned good reputation among the customers.
R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit 13
R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit 14
R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit 15
R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit 16
R123 rreon recovery system ac recharge machine low pressure R1233zd refrigerant recovery unit 17




WHY CHOOSE CM REFRIGERATION

>> You want experience…
Experienced R&D team bring more than 10 years of process cooling & heating experience with knowledgeable application, product and service specialists available to discuss your needs.

>> You want someone who understands your process…
Provided with experience in a wide range of process cooling & heating industries. When you give us the chance, we will show the rich experience and get you the correct solution to your problems.

>> You want a product that fits your unique needs…
Offer a wide range of standard units, what's more, our application specialists can suggest the customized units to meet unique needs.

>> You want professional design manufacturer…
We specialize in industrial refrigerant recovery machine (recovery/recharge/reclaim/vacuum /etc), and provide the complete systems solutions.

>> Our Warranty
All the products are passed strict test, and CM Refrigeration provide 12 months guarantee since the date of bill of lading. During this guarantee period, CM Refrigeration provide spare parts without any charge in case of quality discrepancy caused by us. If out of guarantee period, we still can charge the buyer cost price of spare parts and provide Technical Product support for customers.

>> Our Service:
- OEM & ODM, or any other unique customized demands are acceptable.
- Any price inquiries or technical inquiries will be responded within 24 hours.
- Experienced technical engineers will give the model selection guide or help design the customized model.
- Detailed quotation scheme and system configuration will be provided to the customer together.
- The whole order process is tracked throughout:
Technical proposal communication → Order production → Performance test → Packaging→ Necessary documents confirmation →Transportation → Customs declaration → Shipping→ Installation assistance(provide user manual or install video) → After-sales support. Buyer will receive the notification mail (include photos, report or other documents) in each process.
- Besides the temperature control units, other install parts or auxiliary equipment is optional according to customers'
requirements.
- All necessary installation documentation (e.g. Electrical diagram, User Manual) will be provided in both electronic copy and hard copy.
- Perfect after-sales service system, it's including: Technical guidance, detailed machine maintenance methods, troubleshooting, solutions, regular return visit etc.
