Full Oil Less 7HP Refrigerant Recovery Machine Fast Speed Large R134a Refrigerant Recovery Charging Equipment

Condition

New
Applicable Industries

Machinery Repair Shops, Manufacturing Plant
Weight (KG)

350
Showroom Location

None
Video Outgoing-inspection

Provided
Machinery Test Report

Not Available
Warranty Of Core Components

1 Year
Core Components

Motor
Type

COMPRESSOR
Warranty

1 Year
After-sales Service Provided

Engineers Available To Service Machinery Overseas
Color

Blue
Refrigerant

R134a/R22/R410a
Compressor

7.5HP Oil-free
Model No

WFL18 Air-Cooled Refrigerant Recovery Machine
Vapor Recovery Rate

≤180kg/h
Pull/Push Recovery Rate

≤9000kg/h
Application Scope

≤3000kg
Maintenance Site

Large HVAC/R Products
Certificate

CE
Port

Shanghai
Place of Origin

Jiangsu, China
Brand Name

CM
Price

$11,000.00/units 1-1 units
Packaging Details

wooden case/pallet WFL18 Middle Low Pressure Refrigerant Recovery Charging Machine
Supply Ability

50 Unit/Units per Month

Full Oil Less 7HP Refrigerant Recovery Machine Fast Speed Large R134a Refrigerant Recovery Charging Equipment

Name: Full Oil Less 7HP Refrigerant Recovery Machine Fast Speed Large R134a Refrigerant Recovery Charging Equipment
Brand: Nanjing Wonfulay Precision Machinery Co., Ltd.
Availability: InStock

button button

Get Price Contact Now

Product Description

WFL16/WFL18 R22 refrigerant auto ac recharge and recovery machine

Advantages
• Performance has become a forefront of the industry and meet ARI-700 standards;
• Universal for CFC/HCFC/HFC of medium & low pressure refrigerants;
• 24-hour continuous working;
• No need for special maintenance when recovery different refrigerants, just evacuation.
• No cross contamination;
• High performance/price ratio - rapid investment return Maintenance is simple.

Product Feature of WFL16/WFL18 R22 refrigerant auto ac recharge and recovery machine
• Oil-free lubricating compressor - compatible with CFC/HCFC/HFC refrigerants
• Fast recovery recharging rate for both liquid and vapor refrigerants
• Multi-function valve design- simple operation in vapor and push/pull recovery
• Perfect protection system - safe credibility;
• Thorough recovery refrigerant and automatic stop when the suction pressure is up to -0.04Mpa
• Easy to operate and convenient to move;
• Perfect protection system- safe credibility;
• Water/cooled design - Effective heat dissipation;
• For 3000kg cooling system, finish all the refrigerant recovery within 5 hours;

Model	Oil-free Compressor	Vapor Recovery Rate	Pull/Push Recovery Rate	Scope of Application
WFL16	5 HP	≤120kg/h	≤6000kg/h	≤2000kg
WFL18	7.5 HP	≤180kg/h	≤9000kg/h	≤3000kg

Working & Environmental Temp.: -10-60 degree
Cooling Type: water cooled( air cooled is optional)
Recovery Mode: Vapor & Push/Pull Liquid Recovery
Hose: 3/4"

Voltage of WFL16 R22 refrigerant auto ac recharge and recovery machine (optional)
50Hz/3PH/380V 50Hz/3PH/400V
50Hz/3PH/415V 60Hz/3PH/380V
60Hz/3PH/440V 60Hz/3PH/460V

Optional Accessories

1/2" connecting hose(length is customizable)
3/8" connecting hose(length is customizable)
5/8" connecting hose(length is customizable)
3/4" connecting hose(length is customizable)
3/4" to 3/8" adapter
3/4" to 1/4" adapter
3/4" to 5/8" adapter
3/4" filter
Cylinder (20L-1000L) customizable
Float switch for cylinder
(length of power cord is customizable)

a

Transfer refrigerants from ISO tank to tonnage tank;
Service chillers & other large & medium cooling systems below 3000 cooling ton;
Large & medium central A/C factories;
On site maintenance of lage & medium HVAC/R products
