·Oil-free compressor to be compatible with CFC/HCFC/HFC refrigerants
·Ultra fast recovery rate for both liquid and vapor refrigerants
·One valve to exchange vapor and liquid recovery without hose disconnection
·HP and LP shut off;
·Optional air cooled
·Low vacuum degree -0.07Mpa allow recovery more refrigerant
·Utilizes oil separator and filter drier
·Long compressor working life
·Continuously running for 24 hours duty cycle
·Can be customized for flammable refrigerants
Application
HVAC equipment field service
Refrigerant storage tank residual gas recovery
Explosion Proof Refrigerant Recovery Machine Air Conditioning Ac Gas Recovery Unit R134a Recovery System
-
Highlight
Explosion Proof Refrigerant Recovery Machine
,Ac Gas Recovery Refrigerant Recovery Machine
-
ConditionNew
-
Applicable IndustriesManufacturing Plant
-
Weight (KG)300
-
Showroom LocationNone
-
Video Outgoing-inspectionProvided
-
Machinery Test ReportNot Available
-
Warranty Of Core Components1 Year
-
Core ComponentsMotor
-
TypeRefrigerant Recovery Machine
-
Warranty1 Year
-
Product NameOil Less 4HP Refrigerant Gas Recovery Machine
-
Compressor4HP Oil-less Compressor
-
RefrigerantR290, R600A, R32, R1234ZE, R1234YF,R22
-
Voltage380V/50Hz
-
Model NoCM-V400 Refrigerant Recycling Recharge Machine
-
ApplicationRefrigerant Factory, Lab, Chemical Factory, Etc
-
Vapor Recovery Rate60kg/h
-
Liquid Recovery Rate1300kg/h
-
Explosion ProofYes
-
CertificateCE, ATEX
-
Place of OriginJiangsu, China
-
Brand NameCM
-
Model NumberCM-V400
-
Price$8,500.00/units 1-2 units
-
Packaging DetailsPlywood case on pallet for CM-V400 Explosion Proof Refrigerant Gas Recycling Recovery Station
-
Supply Ability50 Unit/Units per Month
Explosion Proof Refrigerant Recovery Machine Air Conditioning Ac Gas Recovery Unit R134a Recovery System
4HP Explosion Proof Refrigerant Recovery Machine Air Conditioning Ac Gas Recovery Unit R134a Recovery System
Product Description
CM-V400 Explosion Proof Refrigerant Recovery Machine for HVAC Equipment Field Service
|
Model
|
CM-V400-5IIA3EP
|
|
Horsepower
|
4HP
|
|
Compressor Displacement
|
5m³/h
|
|
Compressor Type
|
SS304 oil-free reciprocating
|
|
Vapor Recovery
|
≤60Kg/h
|
|
Liquid Push&Pull Recovery Rate
|
≤2000Kg/h
|
|
Cooling
|
Air Cooled
|
|
Applicable Refrigerant
|
R290/R600A/R32/R410A/R134a/R22 etc.
|
|
Gas Leakage Monitoring
|
Yes
|
|
HP Shut-off
|
Yes
|
|
LP Shut-off
|
Yes
|
|
Oil Separator
|
Yes
|
|
Power Source
|
380V 50Hz 3Phase/220V 50Hz 1Phase
|
|
Certification
|
ATEX
|
Advantage and Features
Related Product
Electric Oil Pump
Manual Oil Pump
Steel Cylinder
Vacuum Pump
Trolley Tube Pipe Cleaner
Portable Tube Pipe Cleaner
Why Choose Us
>> You want experience…
Experienced R&D team bring more than 10 years of process cooling & heating experience with knowledgeable application, product and
service specialists available to discuss your needs.
>> You want someone who understands your process…
Provided with experience in a wide range of process cooling & heating industries. When you give us the chance, we will show the
rich experience and get you the correct solution to your problems.
>> You want a product that fits your unique needs…
Offer a wide range of standard units, what's more, our application specialists can suggest the customized units to meet unique
needs.
>> You want professional design manufacturer…
We specialize in industrial refrigerant recovery machine (recovery/recharge/reclaim/vacuum /etc), and provide the complete systems
solutions.
>> Our Warranty
All the products are passed strict test, and CM Refrigeration provide 12 months guarantee since the date of bill of lading. During
this guarantee period, CM Refrigeration provide spare parts without any charge in case of quality discrepancy caused by us. If out
of guarantee period, we still can charge the buyer cost price of spare parts and provide Technical Product support for customers.
>> Our Service:
- OEM & ODM, or any other unique customized demands are acceptable.
- Any price inquiries or technical inquiries will be responded within 24 hours.
- Experienced technical engineers will give the model selection guide or help design the customized model.
- Detailed quotation scheme and system configuration will be provided to the customer together.
- The whole order process is tracked throughout:
Technical proposal communication → Order production → Performance test → Packaging→ Necessary documents confirmation
→Transportation → Customs declaration → Shipping→ Installation assistance(provide user manual or install video) → After-sales
support. Buyer will receive the notification mail (include photos, report or other documents) in each process.
- Besides the temperature control units, other install parts or auxiliary equipment is optional according to customers'
requirements.
- All necessary installation documentation (e.g. Electrical diagram, User Manual) will be provided in both electronic copy and
hard copy.
- Perfect after-sales service system, it's including: Technical guidance, detailed machine maintenance methods, troubleshooting,
solutions, regular return visit etc.
Experienced R&D team bring more than 10 years of process cooling & heating experience with knowledgeable application, product and
service specialists available to discuss your needs.
>> You want someone who understands your process…
Provided with experience in a wide range of process cooling & heating industries. When you give us the chance, we will show the
rich experience and get you the correct solution to your problems.
>> You want a product that fits your unique needs…
Offer a wide range of standard units, what's more, our application specialists can suggest the customized units to meet unique
needs.
>> You want professional design manufacturer…
We specialize in industrial refrigerant recovery machine (recovery/recharge/reclaim/vacuum /etc), and provide the complete systems
solutions.
>> Our Warranty
All the products are passed strict test, and CM Refrigeration provide 12 months guarantee since the date of bill of lading. During
this guarantee period, CM Refrigeration provide spare parts without any charge in case of quality discrepancy caused by us. If out
of guarantee period, we still can charge the buyer cost price of spare parts and provide Technical Product support for customers.
>> Our Service:
- OEM & ODM, or any other unique customized demands are acceptable.
- Any price inquiries or technical inquiries will be responded within 24 hours.
- Experienced technical engineers will give the model selection guide or help design the customized model.
- Detailed quotation scheme and system configuration will be provided to the customer together.
- The whole order process is tracked throughout:
Technical proposal communication → Order production → Performance test → Packaging→ Necessary documents confirmation
→Transportation → Customs declaration → Shipping→ Installation assistance(provide user manual or install video) → After-sales
support. Buyer will receive the notification mail (include photos, report or other documents) in each process.
- Besides the temperature control units, other install parts or auxiliary equipment is optional according to customers'
requirements.
- All necessary installation documentation (e.g. Electrical diagram, User Manual) will be provided in both electronic copy and
hard copy.
- Perfect after-sales service system, it's including: Technical guidance, detailed machine maintenance methods, troubleshooting,
solutions, regular return visit etc.
Our Company
CM factory, Nanjing Wonfulay Precision Machinery Company Ltd, is located in Nanjing, China. Ever since its establishment in 1990s, CM dedicates itself to R&D and manufacturer of refrigerant recovery systems(recovery/ recharge/ reclaim/ vacuum/etc). With its unremitting efforts and more than 20 years of experience, their refrigerant recovery systems have got several national and international patents and their machines have earned good reputation among the customers.
Exhibition
CM(ChunMu)@ChinaRefrigerationExpo
Packing & Delivery
Packing: carton, pallet, wooden case.
Delivery time: within 7-30 days after receiving the payment.
