Chiller Maintenance 3000L Refrigerant Tank Storage Recovery Machine AC Gas Recycling Charging Machine Tank Recovery System

Chiller Maintenance 3000L Refrigerant Tank Storage Recovery Machine AC Gas Recycling Charging Machine Tank Recovery System

  • Condition
    New
  • Applicable Industries
    Manufacturing Plant, Other
  • Weight (KG)
    500
  • Showroom Location
    None
  • Video Outgoing-inspection
    Provided
  • Machinery Test Report
    Not Available
  • Warranty Of Core Components
    1 Year
  • Core Components
    Motor, Pump
  • Type
    COMPRESSOR
  • Warranty
    1 Year
  • Horsepower
    10HP
  • Power Source
    380V50Hz
  • Refrigerant
    R32 R1234ze R134a R410A
  • Storage Tank Capacity
    3000L Or Customized
  • Vapor Recovery Rate
    ≤200kg/h
  • Pull/Push Recovery Rate
    ≤5500kg/h
  • Compressor
    Oil Free
  • Application Field
    Large Chiller Field Service
  • Suction Pressure
    -0.04Mpa
  • Port
    Beijing Shanghai Tianjin Qingdao
  • Place of Origin
    Jiangsu, China
  • Brand Name
    CM
  • Certification
    ce
  • Price
    $26,400.00/cartons 1-1 cartons
  • Packaging Details
    10HP Oil free refrigerant recovery machine with storage tank<br>Package: inner paced by carton box or plywood case, outer paced on pallet
  • Supply Ability
    50 Carton/Cartons per Month

Chiller Maintenance 3000L Refrigerant Tank Storage Recovery Machine AC Gas Recycling Charging Machine Tank Recovery System

CM-T1800 Refrigerant Recovery & Storage System

CM series refrigerant recovery storage system was specially designed for large chiller field service, the system utilizes truly oil less refrigerant recovery compressor with compact design which offers all the features a field service technician needs. These compact, portable, self-contained units are easy to operate for fast chiller evacuation.it helps make the set up and refrigerant transfer process at an efficient, safe, and quick procedure by incorporating features that are important to HVAC technicians.



Application

 Specially designed for large chiller field service.
 Features & Advantages

1. Oil-free compressor - compatible with CFC/HCFC/HFCrefrigerants
2. Exchange valve design-no need to exchange pipeline when recovery liquid/vapor
3. Safe with perfect system protection;
4. Thorough recovery refrigerant and automatic stop at-0.04Mpa
5. Various types of storage tanks are available;

 Specification

Model Compressor Vapor recovery rate Push/pull recovery rate Storage tank capacity Voltage
CM5000/V400-1000L 2-4HP
≤40-60 kg/h
≤1300-1900 kg/h
1000L 380V/50Hz
WFL16/18-2000L 5-7.5HP
≤110-150kg/h
≤3000-4000 kg/h
2000L 380V/50Hz
CM-T1800-3000L 10HP
≤200kg/h
≤5500 kg/h
3000L 380V/50Hz
CM580-5000L 25HP
≤350kg/h
≤10000 kg/h
5000L 380V/50Hz



Chiller Maintenance 3000L Refrigerant Tank Storage Recovery Machine AC Gas Recycling Charging Machine Tank Recovery System 0Chiller Maintenance 3000L Refrigerant Tank Storage Recovery Machine AC Gas Recycling Charging Machine Tank Recovery System 1

Related Products

Chiller Maintenance 3000L Refrigerant Tank Storage Recovery Machine AC Gas Recycling Charging Machine Tank Recovery System 2

Application Scene

Chiller Maintenance 3000L Refrigerant Tank Storage Recovery Machine AC Gas Recycling Charging Machine Tank Recovery System 3

Company Information

ChunMu Refrigeration(CM) is a 24-year comprehensive hi-tech enterprise in R&D, manufacturing oil less refrigerant recovery/reclaim/charging machine in HVAC/R industry. Our main products cover refrigerant recovey unit, refrigerant recovery and reclaim unit, refrigerant recovery recharge unit, R32 recovery unit, R1234yf recovery reclaim unit, high pressure/low pressure recovery unit, R290, R600 anti-explosive recovery machine, multiple-station refrigerant split filling machine,etc.

Our aim is to help clients fulfil Zero Refrigerants Discharge and eco-friendly life environment for our people.

History

1998

CM founded in 1998, entered the HVACR industry as refrigerant recovery,reclaim and charging solution provider and manufacturer

2004-2006

2004,successfully launched first generation portable type residential refrigerant recovery unit,featured by compact design,fast recovery rate with pull rod design,after then,it certificated by CE and ISO-9001 and become the most popular recovery unit in the world.

2007-2009

2009,successfully launched commercial and industrial refrigerant recovery recycling system and been authorized by York of Johnson Control to be manufacture refrigerant recovery system with York brand,meanwhile,the industrial recovery machine passed the inspection of York engineering team which capable o

2010-2014

2010,York ex chief engineer Dr Lee joined CM R&D engineering  team,  meanwhile 25HP rapid refrigerant recovery machine lanuched and been export to Saudi Arabia Ghawar oil field.By the fast recovery rate and unmatched performance,it's been highly praised by the users.

f recovering 3 tons refrigerant within 4hours.

Workshop

Chiller Maintenance 3000L Refrigerant Tank Storage Recovery Machine AC Gas Recycling Charging Machine Tank Recovery System 4

 Exhibition and Clients' Visit

Chiller Maintenance 3000L Refrigerant Tank Storage Recovery Machine AC Gas Recycling Charging Machine Tank Recovery System 5Chiller Maintenance 3000L Refrigerant Tank Storage Recovery Machine AC Gas Recycling Charging Machine Tank Recovery System 6

Chiller Maintenance 3000L Refrigerant Tank Storage Recovery Machine AC Gas Recycling Charging Machine Tank Recovery System 7Chiller Maintenance 3000L Refrigerant Tank Storage Recovery Machine AC Gas Recycling Charging Machine Tank Recovery System 8

Certifications

Chiller Maintenance 3000L Refrigerant Tank Storage Recovery Machine AC Gas Recycling Charging Machine Tank Recovery System 9Chiller Maintenance 3000L Refrigerant Tank Storage Recovery Machine AC Gas Recycling Charging Machine Tank Recovery System 10

FAQ

Q1: Could I get some samples?

A1: Yes, sample orders welcomed, maybe you could purchase 1 sample for testing,sample not for free.

Q2:Do you have your own factory?

A2: Yes, we are professional manufacturer in this industry over 24 years.

Q3: Could I use my own logo or design on goods?

A3: Yes,Customized logo and design are available for mass production . but we have MOQ

for OEM.

Q4: May I visit your factory?

A4: Sure, warmly welcomed. Factory add.:No.27, Bofu Road, Intelligent Manufacturing Industry Zone, Liuhe District, Nanjing.

Q5: What is the payment team?

A5: T/T, L/C at sight, Western Union,etc.

Q6: What is the delivery time?

A6: Depends on the actual situation, if in stock, we can delivery goods within 2 days after getting the payment; Otherwise, our common lead time15-25 days after getting the deposit.

Q7: How can I trust you?

A7: We have our own factory in China, you can visit us for our field production any time. We also are "Alibaba" verified supplier over 10 years. You can place Trade Assurance Order and pay us through Alibaba, which is as the third party to assure our two sides profits, to be mutual and equal for us.

Q8: How long is your machine warranty period?

A8: The machine warranty period is 1 year after sale. After the warranty expires, we will provide technical and maintenance support for life. We also can supply the spare parts at favored price.

Q9: How do you obtain technical parameters of machine?

A9: Our technical parameters are our laboratory theoretical data, take refrigerant R410A for example, the numerical value of saturated gas pressure tested in the laboratory, under the actual on-site using condition, the machine has the highest initial recovery speed, but with the inlet pressure of the recycling machine will slowly become smaller and smaller, the recovery speed will also be slower and slower in parabola tendency.

Q10: What about your products advantages?

A10: 1) Chunmu Refrigeration is a 24-year professional manufacturer providing solutions for refrigerant recovery,filling,recycling, we have excellent after sales service system, can help clients solve problems fast and timely. We also have different function machines to help clients solve different actual problems to reduce operation cost.

2) We have 1 year warranty, and we will provide technical and maintenance support for life if warranty expired, also supply spare parts at favored price.

3) Our machines are exported accord with export standard, also pass CE certificate, some special machines have ATEX certificate

4) We have our own laboratory, to provide the experiment data through simulated temperature of -10-50the whole day, to simulate the whole day accuracy and stability of the machine, thats why our charging machine has the higher accuracy and stability. At present, rarely manufactures have such laboratory In China.
