automatic refrigerant split charging machine ac recharge machine R134a R22 refrigerant recovery filling machine
-
ConditionNew
-
Applicable IndustriesManufacturing Plant
-
Weight (KG)400
-
Showroom LocationNone
-
Video Outgoing-inspectionProvided
-
Machinery Test ReportNot Available
-
Warranty Of Core Components1 Year
-
Core ComponentsMotor
-
TypeCOMPRESSOR
-
Warranty1 Year
-
After-sales Service ProvidedEngineers Available To Service Machinery Overseas
-
ColorBlue
-
CompressorOil-free
-
RefrigerantR134A/R22/R407C/R410A
-
Model NoCM20A Refrigerant Sub Package Filling Machine
-
Filling Accuracy0.5%
-
Filling Rate6kg/min
-
Scale Measurement Range40kg/100kg/150kg/200kg(optional)
-
Vacuum Pump4L/s (3 Units)
-
Each Station Recovery Rate2-3kg/min
-
PortShanghai Ningbo Qingdao Shenzhen
-
Place of OriginJiangsu, China
-
Brand NameCM
-
CertificationCE ATEX
-
Model NumberCM20A
-
Minimum Order Quantity1 Unit
-
Price$19,200.00/units 1-4 units
-
Packaging DetailsCarton box or plywood case on pallet for CM20 Refrigerant Filling Machine (Multiple Stations Sub Package Recovery Machine)
-
Supply Ability50 Unit/Units per Month
automatic refrigerant split charging machine ac recharge machine R134a R22 refrigerant recovery filling machine
CM20A Multiple-Station Refrigerant filling machine is for the application that Transfer refrigerant from ISO TANK or 1000-400L tank to 12L-60L tank. It integrates functions of vacuum, recharge and pumpback. Three stations can work simultaneously, so subpackage efficiency is very high. The accuracy is 0.5%.
Features
CM20A multiple-stage Refrigerant sub-package machine
1) Integrate functions of vacuum, filling, and pumpback - high efficiency and no refrigerant loss;
2) Use special booster oil-free compressor, can subpackge various refrigerants like R22/R134A/R410A etc;
3) Suitable for transferring refrigerants from ISO tank or 1000-400L tank to 12-60L cylinder;
4) Refrigerant filling completely, and auto-stop when the pressure of supply tank is up to -0.04MPA;
5) Three working-station design, high filling efficiency;
6) Overall protection system, safe credible;
7) Filling accuracy is 0.5%;
8) Can make according to customers' requirements.
Specification
CM20A multiple-stage Refrigerant subpackage machine
|
Model |
Booster compressor |
Vacuum Pump |
Refrigerants |
Filling speed |
Scale measurement range |
|
CM20 |
Oil-less
|
2L/S×3PCS |
R410A/R22/ R134A, etc |
≤6kg/min |
40kg/100kg/150kg/200kg(optional) |
|
CM20A |
Oil-less |
4L/S×3PCS |
R410A/R22/ R134A, etc |
≤6kg/min |
40kg/100kg/150kg/200kg(optional) |
• CM20 multiple-stage refrigerant subpackage machine
• 24-hour continuous working
• No cross contamination
• Applicable for all refrigerants
ChunMu Refrigeration,well know as "CM" was established in 1998, a comprehensive hi-tech enterprise specialized in R&D, manufacturing oil less refrigerant recovery,reclaim and charging equipment in HVAC/R industry. In the past 24 years,CM provides one stop engineering and manufacturing designed to provide its’ customers with customized solutions
to meet their commercial and residential HVAC service needs. Whatever your HVAC service needs may be, CM has the knowledge and expertise to solve your problems.With the environmental pollution of traditional refrigerants a large number of traditional refrigerants need to be recycled and reused, and new environmentally friendly refrigerants have been invented in recent years, giving the company a development belt. With new opportunities, CM has continuously increased its R&D investment in recent years. It has developed many new products such as R600/R290/R1234yf to meet the individual needs of different customers and helped many companies reduced refrigerant waste in production and maintenance process and save large amount funds for, protecting the environment.
