10HP R32 Refrigerant Recovery Machine With Atex Certification

10HP R32 Refrigerant Recovery Machine With Atex Certification

Products - Refrigerant Recovery Machine
  • Highlight

    10HP Refrigerant Recovery Machine

    ,

    R32 Refrigerant Recovery Machine

    ,

    10HP automotive freon recovery machine

  • Condition
    New
  • Applicable Industries
    Machinery Repair Shops, Retail, Energy & Mining, Other
  • Weight (KG)
    245
  • Showroom Location
    None
  • Video Outgoing-inspection
    Provided
  • Machinery Test Report
    Provided
  • Warranty Of Core Components
    6 Months
  • Core Components
    Engine, Motor
  • Type
    Condenser
  • Warranty
    1 Year, 1 Year
  • Name
    Refrigerant Charging Station
  • Refrigerants
    R410A,R22,R134A,R404A,R407C
  • Compressor
    10 Hp Oil-less
  • Model No
    CM-T1800
  • After-sales Service Provided
    Free Spare Parts
  • Voltage
    380V/50HZ Made To Order
  • Inlet&Outlet Size
    3/4"
  • Vapor Recovery Rate
    ≤289kg/h (depends On Fitting&hose Size And Pressure)
  • Port
    Shang Hai Port
  • Place of Origin
    Jiangsu, China
  • Brand Name
    CM
  • Certification
    ce, Atex
  • Model Number
    CM-T1800
  • Minimum Order Quantity
    1 Unit
  • Price
    $14,400.00/units 1-4 units
  • Packaging Details
    standard export package plywood case with pallet

10HP R32 Refrigerant Recovery Machine With Atex Certification

  • 10HP R32 Refrigerant Recovery Machine With Atex Certification
  • 10HP R32 Refrigerant Recovery Machine With Atex Certification
  • 10HP R32 Refrigerant Recovery Machine With Atex Certification
  • 10HP R32 Refrigerant Recovery Machine With Atex Certification
Get Price Contact Now

Explosion Proof Air Conditioning Refrigerant Recovery Machine Charging Station 10hp R32 Recovery Unit



Explosion proof air conditioning gas charging device Refrigerant Charging Station



Product Overview



Refrigerant Charging Station CM-T1800 Refrigerant recovery & charging system

FEATURES AT A GLANCE
Advantages
Performance has become a forefront of the industry and meet ARI-700 standards;
Universal for CFC/HCFC/HFC of medium & low pressure refrigerants;
24-hour continuous working;
No need for special maintenance when recovery different refrigerants, just evacuation. No cross contamination;
High performance/price ratio - rapid investment return Maintenance is simple.
10HP R32 Refrigerant Recovery Machine With Atex Certification 0
PRODUCT SPECIFICATIONS
No
Item
Data
1
Model
CM-T1800
2
Serial N0
20IIIA7.5EP
3
Comperssor
10HP Oil free
4
Vapor Recovery Rate
<200kg/h
5
Liquid Push&Pull Recovery Rate
<9000kg/h
6
Voltage
380V/50HZ
Application

Refrigerant Reclaim System WFL18 Refrigerant Recovery Machine
Transfer refrigerants;
Service chillers & other large & medium cooling systems below 3000 cooling ton;
Large & medium central A/C factories;
On site maintenance of lage & medium HVAC/R products

Features
Oil-free lubricating compressor – compatible with CFC/HCFC/HFC refrigerants
Fast recovery recharging rate for both liquid and vapor refrigerants
Multi-function valve design- simple operation in vapor and push/pull recovery
Perfect protection system – safe credibility;
Thorough recovery refrigerant and automatic stop when the suction pressure is up to -0.04Mpa
Easy to operate and convenient to move;
Perfect protection system- safe credibility;
Water/cooled design - Effective heat dissipation
For 3000kg cooling system, finish all the refrigerant recovery within 5 hours;


CM-T1800 Refrigerant recovery & charging system

Specification
Model: CM-T1800 Refrigerant Recovery Machine
Compressor: 7.5HP, oil free
Vapor Recovery Rate: ≤6.6lbs/min(180kg/h)
Push/Pull Recovery Rate: ≤330lbs/min(9000kg/h)
Working & Environmental Temp.: -10-60°C
Cooling Type: water cooled( air cooled is optional)
Recovery Mode: Vapor & Push/Pull Liquid Recovery
Hose:3/4"
10HP R32 Refrigerant Recovery Machine With Atex Certification 1
10HP R32 Refrigerant Recovery Machine With Atex Certification 2
10HP R32 Refrigerant Recovery Machine With Atex Certification 3
10HP R32 Refrigerant Recovery Machine With Atex Certification 4
